Description
- INPUT VOLTAGE: 120VAC 50/60Hz input
- OUTPUT VOLTAGE: Constant Voltage 12VDC or 24VDC output
- DIMENSION: 6.77 in x 2.67 in x 1.26 in
- POWER FACTOR: >0.95
- THD: <20%
- MINIMUM LOAD: 8W
- PROTECTIONS: Auto-reset protection for short circuits and over-voltage
- IP RATING: IP20 Indoor Use Only
- CERTIFICATIONS: UL Listed
- CONNECTION TYPE: Bare connection wire
- EFFICIENCY: >90%
- IN-RUSH CURRENT: 0.20A @ 12V/24V
- DIMMING RANGE: Down to 1%
- MAX AMBIENT TEMP: -22F to 122F
- WARRANTY: 5 Year Warranty
Features:
- Dim to 1% with Forward Phase (TRIAC) dimmers
- Integrated wiring compartment
- >90% efficiency provides low operating temps
Product Details:
Magnitudes E-Series dimmable low voltage drivers are class 2 rated, designed to work with Forward Phase (TRIAC) dimmers. Encased in a low profile aluminum enclosure that includes two knock-outs for easy installation, it’s the perfect choice for low-voltage under cabinet lights, tape lights and various LED fixture installations. Driver features auto reset, over current and short circuit protection, and an efficiency of 90% or higher for operation at low temperatures.
Are strain reliefs included?
As of October 2025, Magnitude Lighting transformers and LED drivers no longer include metal strain reliefs (also known as electrical grommets, cord grips, or cable clamps).
Because installation requirements, wire types, and knockout sizes vary by application, installers must provide the appropriate UL-listed strain relief or cable clamp for their installation. All components should be properly sized for the cable and knockout being used and installed in accordance with applicable local electrical codes.
